Motic Microscopio stereo zoom SMZ143-N2GG

Prodotto n.: 48008
Produttore: Motic

$ 720,00

IVA incl.
Descrizione prodotto
Specifiche
Recensioni clienti
Accessori raccomandati
Downloads

Descrizione prodotto:

Purtroppo, questa descrizione non è stato tradotto in italiano, in modo da trovare a questo punto una descrizione inglese.

SZM-140

Make use of the convenience and versatility of seeing a large part of your sample image at 10X magnification, then zooming continuously to close-up details at 40X…or any point in between. The SMZ140 Series offers a high optical performance combined with a special designed incident and transmitted intensity controlled halogen illumination.

SMZ-140 N2GG - SMZ-143 N2GG

45° inclined binocular (SMZ-140) or trinocular (SMZ-143) head, rotates 360°

Beam splitter from left eyepiece tube

Widefield eyepieces 10X/20mm with diopter adjustment

1:4 Zoom ratio, total standard magnification 10X through 40X with click stops at 10X, 20X, 30X and 40X

80mm Working distance

Heavy Duty rack and pinion focusing block with slip clutch

Pole stand with incident and transmitted Halogen Illumination with separate on/off switch

Top Light: 12V/15W; Bottom Light 12V/10W with combined intensity control

Supplied standard with 80mm stage plates (frosted glass, black and white)

SMZ-143-N2GG

Optical System: Greenough

Observation Tube: Trinokclar head

Interpupillary distance: 54-76mm

Diopter adjustment: On both tubes , +/- 5 diopter

Inclination: 45° inclined, 360º rotating

Eyepieces: WF10X/20mm

Objectives system: Zoom, ratio1:4

Objectives magnification: 1X~4X

Working distance: 80mm

Stand: Pole type stand with transmitted illumination

Base: 237x170mm

Column/Arm: Ø25mm, 266mm high

Head holder: For Ø25mm column and Ø74mm head with incident illumination

Focus mechanism: Coarse focusing system with tension adjustment

Focusing stoke: 49mm

Incident illumination: Halogen 12V/15W with intensity control

Transmitted illumination: Halogen 12V/10W with intensity control

Transformer: Internal

Power supply: 220V

Accessories included: Black, white and frosted stage plates and dust cover

Length x Width x Height: 237x170x335mm

Weight: 6,2Kg
